Samcom Sled-X2 Self-Contained White Led Emergency Exit Light

Sled- X2 Self-Contained White Led Emergency Exit Light

The designed is thin and lightwight, lowest power consumption, minimize EMI and specially equipped with a customised proprietary Hybrid IC, super-bright white LED and longer life-span. Easy and fast installation. Enviroment for Factories, Schools, Stadiums, Banks, Clubs, Hotels, Computer Rooms, Offices, Public Halls, Hospitals, Apartments, Warehouses, Carparks, etc.

Features:

• Hybrid Ic Controlled
• Self-Contained Emergency
• Lighting Super Bright Smt White
• Led Luminaire

Specification:

• Colour: White
• Product Type: Emergency Exit Light
• Input Voltage : 220 ~ 240Vac 50/60Hz ± 10%, A: 0.019 Pf: 0.44
• Battery: 3.6V 0.9Ah High Temp Rated Nickel Cadmium Cells Or Others
• Lamp Used: Smt White Led Strip > 30,000 Hrs
• Rated Period : > 3 Hrs Or Others
• Mode: Maintained
• Operation Temperature: Ta 40 °C
• Power Consumption: 2.5 W
• Charge Monitor: Super Bright Green Led 5Mm Ø
• Recharge Pe Riod: 16 ~ 24 Hrs
• Emergency Luminance: > 8 cd/m2
• Electromagnetic Field: 17m gause @ 0.1m
• Charger: Hybrid Controlled Charger
• Protection: Low Volt Cut-Off To Prevent Battery Over Discharge, Incoming Ac Fuse And Battery Dc Fuse, Tropical Climate Protection Coating On Hybrid Control Circuit
• Construction: Electrode Galvanised Sheet Steel With Epoxy Powder Coating, 20Mm Ø K/O Hole, Fire Retardant Acrylic Diffuser
• Length: 345mm
• Width: 52mm
• Height: 252mm
• Weight : 1.30Kg (Net)/1.47Kg (Gross) With Bracket
• Compliance : IEC 60598-2-22:2014/A1:2017, S563-1:2010, Ss563-2:2010/A1
• Accessory: Wall Mounting Bracket (For Single Face)
