Reference: 20999
Suspension with top fixing plate
Robust
Light and silent action
Track stop, adjustable retaining force
Hawa 11703 Junior 160/A Sliding Door Fitting Set for Single Door
The HAWA-Junior 160/A is a hardware system with bracket suspension for wooden and metal doors weighing up to 160 kg (352 lbs.).
Features:
- Galvanized steel top fixing table for bolting or welding
- Robust
- Light and silent action
- Adjustable vertically [± 4 mm] and laterally
- Track stop, adjustable retaining force
Set Comprises of:
- 2 x Two-wheeled trolley, M14, with plastic wheels
- 1 x Track stop, adjustable retaining force
- 2 x Top fixing plate, galvanized steel, with hanger bolt M14 and fixing screws
- 1 x guide, rattle proof for screw mounting to floor, groove width 14 mm, plastic black
- 1 x Screw-on rubber door stop
Specifications:
- Brand: Hawa
- Product Type: Sliding Door Fitting
- Running Position: Top Running
- Mounting Position: Ceiling Mounting
- Minimum Door Thickness: 35mm
- Maximum Door Thickness: 80mm
- Maximum Width: 3000mm
- Maximum Weight: 160kg
- Maximum Height: 4000mm
