Hawa 220 Planfront System for Sliding Cabinet Doors with Flush Mounting

Hawa 220 Planfront System for Sliding Cabinet Doors with Flush Mounting

The Hawa 220 Planfront 70 offers countless interior design possibilities. Sliding elements may be flush-mounted to a wainscot or cupboard. Projection screens or media walls may be hidden away without the slightest difficulty. The sliding doors can be moved parallel behind a fixed front. The doors can be locked using a standard bar bolt lock. The sliding elements run in the top track and are guided in a bottom guide channel.

Features:

• Space-saving sliding doors with flush mounting
• Effortless operation with smooth sliding mechanism
• Customizable options for tailored solutions
• Durable construction for longevity
• Ideal for small spaces, offering enhanced accessibility
• Versatile applications in residential and commercial settings
• Sleek, modern design elevates any space
• Easy installation for new or existing cabinets

Application:

This hardware system is suitable for use wherever it is required to flush-mount cabinet fronts or wainscots for aesthetic or practical reasons, e.g. in apartments and houses, schoolhouses, conference rooms, etc., and in the industrial and administration sectors.

Sets comprising

• 2 x Two-wheeled trolley, M10, with plastic-tyred ball bearing wheels
• 2 x Top and edge fixed bracket with suspension plate and bolt M10
• 1 x Side fixed guide pin with plastic roller, adjustable
• 1 x Track end stop, alu screw in place
• 6 x Plug rubber, grey, to 10464 and 10540
• 2 x Curved top track, alu plain anodized
• 1 x Curved bottom guide channel, alu plain anodized

Specifications:

• Brand: Hawa
• Product Type: Planfront System
• Door Thickness: 19 - 45mm
• Door Width: 400 - 1500mm
• Door Height: 2600mm
• Maximum Weight: 70kg
